Description :





The product 392167 is an etch based on a lead borosilicate frit.



Colors :





Base etch





Application :





Etch-decorating including cosmetics bottles, bottles and other glass objects.

We recommend not to use this etch in an environment where it comes in direct contact with water and weather influences for a longer period of time.





Conditions :







Screen printing Thermoplastic



Screenprinting

Oil-based IR



Sreenprinting

Water friendly IR



Handpainting,

(Oil-based IR)





Recommended medium:





64-64





485-63



654-63



N485



Recommended thinner:





64-64





RM.323





RM.444

RM.773





RM 362



Powder /medium ratio:





6:1



4:1



4,5:1



4:1





Viscosity:





+ 1,5 Pa.s



15-20 Pa.s



15-20 Pa.s



N.A.





Temperature when applied:





+ 70 ºC



15-20 ºC



Recommended mesh size:



80-160T (200-400 mesh)



61-120T (150-300 mesh)



61-120T (150-300 mesh)







"Wet film" thickness:





20-300 µm



20-40 µm



20-40 µm



20-120 µ





Drying conditions:





Lucht



100-150 ºC



Firing conditions :





550 - 620 ºC (1022 - 1148 ºF)





Resistance :





-- Acid resistance :

- 3.7 % HCl, 15 minutes at roomtemperature

According to the norm  ASTM C 724-91: classe 4 to 5





Surface appearance :



Etch





Presentation :



This etch can be provided in:

- Powder

- Handpaintingmedium

- Waterbased spraying medium

- ThermoPlastic screenprintingmedium

- I.R. drying screenprinting medium (water- or oilbased)





Minimum purchase quantity per color shade:





Colors in powder form:

Color-paste for screen printing:

ThermoPlastic colors for screen printing:





1 kg

2,5 kg

5 kg





Stability :





- Powder :

- Paste :

- ThermoPlast :





5 years after production date

12 months after production date

18 months after production date

(if stored correctly)





Storage :





It is recommended that the product is stored in dry surroundings at room temperature (20ºC, 68ºF) and is not exposed to large temperature shocks





Health & Safety :





Good industrial hygiene and work practices should be adhered to when handling these products. For detailed health and safety requirements, please consult the appropriate Material Safety Data Sheet.





Other information :



N.A.



Notice

Please note that when viewed on different monitors these colors will show slight to dramatic color differences unless the given monitor has been calibrated. The information provided herein is correct to the best of our knowledge. No liability for any errors, facts or opinions is accepted. You should satisfy yourself before applying any of the information contained herein to your particular circumstances. No responsibility for any loss as a result of any person placing reliance on any material contained herein can be accepted by Technical Color Service.

Technical Color Service - Hedikhuizerweg 33 - 5222 BC  's-Hertogenbosch - The Netherlands

Tel. +31 (653) 471 811



Reviewed on: 08-10-2015

Technical Data Sheet: 392167 Etch
